74ACT16652的基本参数
  • 制造厂商:TI
  • 产品类别:逻辑和电压转换
  • 技术类目:缓冲器、驱动器和收发器 - 通用收发器
  • 功能描述:具有三态输出的 16 位收发器和寄存器
  • 点击这里打开及下载74ACT16652的技术文档资料
  • TI代理渠道,提供当日发货、严格的质量标准,满足您的目标价格
快速报价,在行业拥有较高的知名度及影响力
74ACT16652的产品详情:

The 'ACT16652 are 16-bit bus transceivers consisting of D-type flip-flops and control circuitry arranged for multiplexed transmission of data directly from the data bus or from the internal storage registers. The devices can be used as two 8-bit transceivers or one 16-bit transceiver.

Complementary output-enable (OEAB and ) inputs are provided to control the transceiver functions. Select-control (SAB and SBA) inputs are provided to select whether real-time or stored data is transferred. A low input level selects real-time data, and a high input level selects stored data. The circuitry used for select control eliminates the typical decoding glitch that occurs in a multiplexer during the transition between stored and real-time data. Figure 1 illustrates the four fundamental bus-management functions that can be performed with the 'ACT16652.



Data on the A or B bus, or both, can be stored in the internal D flip-flops by low-to-high transitions at the appropriate clock (CLKAB or CLKBA) inputs, regardless of the levels on the select-control or output-enable inputs. When SAB and SBA are in the real-time transfer mode, it is also possible to store data without using the internal D-type flip-flops by simultaneously enabling OEAB and. In this configuration, each output reinforces its input. Thus, when all other data sources to the two sets of bus lines are at high impedance, each set of bus lines remains at its last state.

The 74ACT16652 is packaged in TI's shrink small-outline package, which provides twice the I/O pin count and functionality of standard small-outline packages in the same printed-circuit-board area.

The 54ACT16652 is characterized for operation over the full military temperature range of -55°C to 125°C. The 74ACT16652 is characterized for operation from -40°C to 85°C.



74ACT16652的优势和特性:
  • Members of the Texas Instruments WidebusTM Family
  • Inputs Are TTL-Voltage Compatible
  • Independent Registers and Enables for A and B Buses
  • Multiplexed Real-Time and Stored Data
  • Flow-Through Architecture Optimizes PCB Layout
  • Distributed VCC and GND Pin Configuration Minimizes High-Speed Switching Noise
  • EPICTM (Enhanced-Performance Implanted CMOS) 1-m Process
  • 500-mA Typical Latch-Up Immunity at 125°C
  • Package Options Include Plastic 300-mil Shrink Small-Outline (DL) Packages Using 25-mil Center-to-Center Pin Spacings and 380-mil Fine-Pitch Ceramic Flat (WD) Packages Using 25-mil Center-to-Center Spacings

EPIC and Widebus are trademarks of Texas Instruments Incorporated.

74ACT16652的参数(英文):
  • IOL (Max) (mA)
  • 24
  • IOH (Max) (mA)
  • -24
  • Technology Family
  • ACT
  • Rating
  • Catalog
  • Operating temperature range (C)
  • -40 to 85
74ACT16652具体的完整产品型号参数及价格(美元):

74ACT16652的完整型号有:74ACT16652DL、74ACT16652DLR,以下是这些产品的关键参数及官网采购报价:

74ACT16652DL,工作温度:-40 to 85,封装:SSOP (DL)-56,包装数量MPQ:20个,MSL 等级/回流焊峰值温度:Level-1-260C-UNLIM,引脚镀层/焊球材料:NIPDAU,TI官网74ACT16652DL的批量USD价格:6.588(1000+)

74ACT16652DLR,工作温度:-40 to 85,封装:SSOP (DL)-56,包装数量MPQ:1000个,MSL 等级/回流焊峰值温度:Level-1-260C-UNLIM,引脚镀层/焊球材料:NIPDAU,TI官网74ACT16652DLR的批量USD价格:5.49(1000+)

轻松满足您的TI芯片采购需求
74ACT16652的评估套件:

74ACT16652DL,工作温度:-40 to 85,封装:SSOP (DL)-56,包装数量MPQ:20个,MSL 等级/回流焊峰值温度:Level-1-260C-UNLIM,引脚镀层/焊球材料:NIPDAU,TI官网74ACT16652DL的批量USD价格:6.588(1000+)

74ACT16652DLR,工作温度:-40 to 85,封装:SSOP (DL)-56,包装数量MPQ:1000个,MSL 等级/回流焊峰值温度:Level-1-260C-UNLIM,引脚镀层/焊球材料:NIPDAU,TI官网74ACT16652DLR的批量USD价格:5.49(1000+)
