SN54AHC244-SP的基本参数
  • 制造厂商:TI
  • 产品类别:逻辑和电压转换
  • 技术类目:缓冲器、驱动器和收发器 - 同相缓冲器和驱动器
  • 功能描述:具有三态输出的航天类 8 通道、2V 至 5.5V 缓冲器
  • 点击这里打开及下载SN54AHC244-SP的技术文档资料
  • TI代理渠道,提供当日发货、严格的质量标准,满足您的目标价格
快速报价,在行业拥有较高的知名度及影响力
SN54AHC244-SP的产品详情:

These octal buffers and drivers are designed specifically to improve the performance and density of 3-state memory-address drivers, clock drivers, and bus-oriented receivers and transmitters.

SN54AHC244-SP的优势和特性:
  • Operating Range 2-V to 5.5-V VCC
  • Latch-Up Performance Exceeds 250 mA Per JESD 17
  • On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
SN54AHC244-SP的参数(英文):
  • Technology Family
  • AHC
  • Supply voltage (Min) (V)
  • 2
  • Supply voltage (Max) (V)
  • 5.5
  • Number of channels (#)
  • 8
  • IOL (Max) (mA)
  • 8
  • ICC (Max) (uA)
  • 40
  • IOH (Max) (mA)
  • -8
  • Input type
  • Standard CMOS
  • Output type
  • 3-State
  • Features
  • Balanced outputs, Very high speed (tpd 5-10ns), Over-voltage tolerant inputs
  • Rating
  • Space
SN54AHC244-SP具体的完整产品型号参数及价格(美元):

SN54AHC244-SP的完整型号有:5962-9678201VRA、5962-9678201VSA,以下是这些产品的关键参数及官网采购报价:

5962-9678201VRA,工作温度:-55 to 125,封装:CDIP (J)-20,包装数量MPQ:1个,MSL 等级/回流焊峰值温度:N/A for Pkg Type,引脚镀层/焊球材料:SNPB,TI官网5962-9678201VRA的批量USD价格:85.932(1000+)

5962-9678201VSA,工作温度:-55 to 125,封装:CFP (W)-20,包装数量MPQ:1个,MSL 等级/回流焊峰值温度:N/A for Pkg Type,引脚镀层/焊球材料:SNPB,TI官网5962-9678201VSA的批量USD价格:103.118(1000+)

轻松满足您的TI芯片采购需求
SN54AHC244-SP的评估套件:

5962-9678201VRA,工作温度:-55 to 125,封装:CDIP (J)-20,包装数量MPQ:1个,MSL 等级/回流焊峰值温度:N/A for Pkg Type,引脚镀层/焊球材料:SNPB,TI官网5962-9678201VRA的批量USD价格:85.932(1000+)

5962-9678201VSA,工作温度:-55 to 125,封装:CFP (W)-20,包装数量MPQ:1个,MSL 等级/回流焊峰值温度:N/A for Pkg Type,引脚镀层/焊球材料:SNPB,TI官网5962-9678201VSA的批量USD价格:103.118(1000+)
