TM4C129DNCPDT的基本参数
  • 制造厂商:TI
  • 产品类别:微控制器 (MCU) 和处理器
  • 技术类目:微控制器 (MCU) - 基于 Arm 的微控制器
  • 功能描述:具有 120MHz 频率、1MB 闪存、256KB RAM、USB、ENET MAC+MII 和 AES、基于 Arm Cortex-M4F 的 32 位 MCU
  • 点击这里打开及下载TM4C129DNCPDT的技术文档资料
  • TI代理渠道,提供当日发货、严格的质量标准,满足您的目标价格
快速报价,在行业拥有较高的知名度及影响力
TM4C129DNCPDT的产品详情:

Tiva™ C Series microcontrollers integrate a large variety of rich communication features to enable a new class of highly connected designs with the ability to allow critical, real-time control between performance and power. The microcontrollers feature integrated communication peripherals along with other high-performance analog and digital functions to offer a strong foundation for many different target uses, spanning from human machine interface to networked system management controllers.

In addition, Tiva™ C Series microcontrollers offer the advantages of ARM's widely available development tools, System-on-Chip (SoC) infrastructure, and a large user community. Additionally, these microcontrollers use ARM's Thumb®-compatible Thumb-2 instruction set to reduce memory requirements and, thereby, cost. Finally, the TM4C129DNCPDT microcontroller is code-compatible to all members of the extensive Tiva™ C Series, providing flexibility to fit precise needs.

Texas Instruments offers a complete solution to get to market quickly, with evaluation and development boards, white papers and application notes, an easy-to-use peripheral driver library, and a strong support, sales, and distributor network.

TM4C129DNCPDT的优势和特性:
  • Performance
    • ARM? Cortex?-M4F processor core
    • 120-MHz operation; 150 DMIPS performance
    • 1024 KB Flash memory
    • 256 KB single-cycle System SRAM
    • 6KB of EEPROM
    • Internal ROM loaded with TivaWare? for C Series software
    • 8-/16-/32- bit dedicated External Peripheral Interface (EPI) for peripherals and memory
  • Security
    • Cyclical Redundancy Check (CRC) hardware with 16-/32-bit Hash function that supports four CRC forms
    • Advanced Encryption Standard (AES) hardware-accelerated data encryption and decryption based on 128-, 192-, and 256-bit keys
    • Data Encryption Standard (DES) block cipher implementation with 168-bit effective key length
    • Hardware Accelerated Hash (SHA/MD5) advanced hash engine that supports SHA-1, SHA-2 or MD5 Hash computation
    • Support for four tamper inputs and configurable tamper event response
  • Communication Interfaces
    • Eight Universal Asynchronous Receivers/Transmitters (UARTs)
    • Four Quad Synchronous Serial Interface (QSSI) modules with Bi-, Quad- and advanced SSI support
    • Ten Inter-Integrated Circuit (I2C) modules with four transmission speeds including high-speed mode
    • Two Controller Area Network (CAN) 2.0 A/B controllers
    • 10/100 Ethernet MAC with Media Independent Interface (MII) and Reduced MII (RMII)
    • Universal Serial Bus (USB) 2.0 OTG/Host/Device with ULPI interface option and Link Power Management (LPM) support
  • System Integration
    • ARM? PrimeCell? 32-channel configurable Micro Direct Memory Access (μDMA) controller
    • Eight 16/32-bit General-Purpose Timer (GPTM) blocks
    • Two watchdog timers
    • Low-power battery-backed Hibernation module
    • 15 physical General-Purpose Input/Output (GPIO) blocks
  • Advanced Motion Control
    • One Pulse Width Modulator (PWM) module, with four PWM generator blocks and a control block, for a total of 8 PWM outputs
    • One Quadrature Encoder Interface (QEI) module
  • Analog Support
    • Two 12-bit Analog-to-Digital Converter (ADC) modules, each with a maximum sample rate of one million samples/second
    • Three independent integrated analog comparators
    • 16 digital comparators
  • One JTAG module with integrated ARM Serial Wire Debug (SWD)
  • 128-pin TQFP package
  • Operating Range (Ambient)
    • Industrial (-40°C to 85°C) temperature range
    • Extended (-40°C to 105°C) temperature range
TM4C129DNCPDT的参数(英文):
  • CPU
  • Arm Cortex-M4F
  • Frequency (MHz)
  • 120
  • ADC
  • 12-bit SAR
  • GPIO
  • 90
  • UART
  • 8
  • Number of I2Cs
  • 10
  • Features
  • Hibernation with calendar mode, Hardware encrpytion (AES/DES/SHA/MD5), 8-/16-/32-bit EPI, Ethernet MAC with MII/RMII
  • Operating temperature range (C)
  • -40 to 105, -40 to 85
TM4C129DNCPDT具体的完整产品型号参数及价格(美元):

TM4C129DNCPDT的完整型号有:TM4C129DNCPDTI3、TM4C129DNCPDTI3R、TM4C129DNCPDTT3、TM4C129DNCPDTT3R,以下是这些产品的关键参数及官网采购报价:

TM4C129DNCPDTI3,工作温度:-40 to 85,封装:TQFP (PDT)-128,包装数量MPQ:90个,MSL 等级/回流焊峰值温度:Level-3-260C-168 HR,引脚镀层/焊球材料:NIPDAU,TI官网TM4C129DNCPDTI3的批量USD价格:9.072(1000+)

TM4C129DNCPDTI3R,工作温度:-40 to 85,封装:TQFP (PDT)-128,包装数量MPQ:1000个,MSL 等级/回流焊峰值温度:Level-3-260C-168 HR,引脚镀层/焊球材料:NIPDAU,TI官网TM4C129DNCPDTI3R的批量USD价格:7.776(1000+)

TM4C129DNCPDTT3,工作温度:-40 to 105,封装:TQFP (PDT)-128,包装数量MPQ:90个,MSL 等级/回流焊峰值温度:Level-3-260C-168 HR,引脚镀层/焊球材料:NIPDAU,TI官网TM4C129DNCPDTT3的批量USD价格:9.396(1000+)

TM4C129DNCPDTT3R,工作温度:-40 to 105,封装:TQFP (PDT)-128,包装数量MPQ:1000个,MSL 等级/回流焊峰值温度:Level-3-260C-168 HR,引脚镀层/焊球材料:NIPDAU,TI官网TM4C129DNCPDTT3R的批量USD价格:8.1(1000+)

轻松满足您的TI芯片采购需求
TM4C129DNCPDT的评估套件:

EK-TM4C1294XL — Tiva C 系列 TM4C1294 连接 LaunchPad

EK-TM4C129EXL — TM4C129E Cypto Connected LaunchPad

TMDSEMU200-U — Spectrum Digital XDS200 USB 仿真器

TMDSEMU560V2STM-U — Blackhawk XDS560v2 系统跟踪 USB 仿真器

TMDSEMU560V2STM-UE — Spectrum Digital XDS560v2 系统跟踪 USB 和以太网

DK-TM4C129X — DK-TM4C129X 连接开发套件

UNIFLASH — 适用于大多数 TI 微控制器 (MCU) 和毫米波传感器的 UniFlash

SW-TM4C — 适用于 C 系列的 TivaWare 软件(完整)

SYSCONFIG — SysConfig 独立桌面版本

CCSTUDIO — Code Composer Studio 集成式开发环境 (IDE)

CCSTUDIO-TM4X — 适用于 TM4x MCU 的 Code Composer Studio (CCS) 集成开发环境 (IDE)

ENERGIA — Energia

LLDP Software (Rev. A)

TM4C129DNCPDT 128-TQFP BSDL Model

TM4C129DNCPDT 128-TQFP IBIS Model

TM4C129x Schematic Symbols for PADS

TM4C129x OrCAD Schematic Symbols

TM4C129x Symbols Library

TM4C129DNCPDT的电路图解:
